Coolant
Components
Click image to enlarge
Details
AC110 Technical Data Sheet (English)
| Item | Specification | Description |
|---|---|---|
| Typical Application | General purpose battery and charger cooling | EV Cables & Batteries |
| Appearance | Clear | |
| Fluid Behavior | Non-Compressible, Isotropic, Newtonian | |
| Dielectric Strength | > 60 kV | High Insulation |
| Resistivity | > 1 × 101410 to the 14th power 1014 | |
| Pour Point | -57 ℃ | |
| Flash Point | 193 ℃ | High Safety |
| ISO 4406 Particle Count | 10 / 10 / 2012 | Cleanliness Level |
| Total Sulfur | 0 ppm | Sulfur-free |
| Density (@ 15.6 ℃) | 0.82 g/cc | |
| Viscosity (cSt) | 41.10 (0℃) / 8.11 (40℃) / 2.22 (100℃) | Kinematic |
| Thermal Conductivity | 0.1455 (0℃) / 0.1403 (40℃) / 0.1325 (100℃) | W/m·K |
| Specific Heat | 2.0608 (0℃) / 2.2121 (40℃) / 2.4390 (100℃) | kJ/kg·℃ |
| GWP | 0 | Eco-friendly |
| Biodegradability | > 95% | |
| Material Compatibility | Warranty provided | Safe for components |
| Shelf Life | 25 Years |
